제품 상세 정보:
|
애플리케이션: | 확대 철골 구조물 저장소 | 특징: | 경량 골조 철골 구조물 저장소 |
---|---|---|---|
타입: | 더블 스팬 철골 창고 | Beams&Columns: | H 단면도 강철 |
벽과 지붕: | 강철 클래딩 장 | 익지않는 강철 물자: | Q235B, Q355B, ASTM A36 |
서비스 수명: | 50 년 | 표면 처리: | 페인트 등 |
작동 범위: | 디자인, 제작, 임명 | ||
하이 라이트: | Extension Steel Structure Warehouse,Double Span Steel Structure Warehouse,Double Span steel frame warehouse |
Light Frame Double Span Extension Steel Structure Warehouse Buildings
This is a Light Frame Double Span Extension Steel Structure Warehouse Buildings that is used for the storage of mechanical parts. There is only one row of center columns in the warehouse, which provides a large space for indoor storage. The steel structure warehouse itself has the characteristics of light weight, high strength, strong compressive capacity, and short construction period. In many places, there are many large, diverse, and complex steel structures, civil buildings, etc. The emergence of steel structure warehouses as a new architectural model has swept the traditional architectural model with a strong posture. The emergence of standard steel structure warehouse has provided great help for some manufacturing companies. For example, the seismic performance and open space of a steel structure standard warehouse meet the needs of a manufacturing warehouse.
Item name | Specification | Material Parameter | Technical Treatment |
Column | H shape,Box,steel pipe,Hot rolled sheet | Q235B,Q345B | Paint or Hot dip galvanized |
Beam | H shape,steel Truss,Hot rolled sheet | Q235B,Q345B | Paint or Hot dip galvanized |
Bracing | Steel rod,Steel pipe,Angle steel | Q235B,Q345B | |
Purling | C or Z shape, purling Thickness:1.8mm~3.0mm | Q235B,Q346B | Hot dip galvanized |
Wall and roof panel | EPS,Rock wool,Pu,Glass wool Sandwich panel or Single sheet. | Steel T=0.426~0.8mm,insulation T=50~150mm | Alu-zinc 150g, Fluorocarbon paint |
Door | Sliding or rolling door | Steel or Aluminum sheet,T=1.0~1.5mm | Paint or Hot dip galvanized |
Window | alloy-Glass,Aluminium alloy-shutter | T=1.0~2.0mm | Alloy |
Lighting panel | FRP, T=1.5mm or T=1.8mm | Coefficient of thermal expansion:2.2x10-5/cm/cm/℃ | Light transmittance 85% |
Ventilator | Turbine ventilator, and electric type | Steel,stainless steel,PC | Paint or Hot dip galvanized,304 |
Gutter | Galvanized or stainless steel plate | T=2.0mm | Hot dip galvanized,304 |
Downpipe | PVC pipe,Color steel pipe T=0.5mm | Φ110,160,200 | Paint |
Bolt | Ordinary, high strength | 10.9S,4.8s | Hot dip galvanized |
Anchor bolt | Steel rod M24,M27 M30 | Q235B |
All the structure components, panels,bolts and sort of accessories will bewell packed with standard package suitable ocean transportation and loaded into 40’HQ.
All the products are loaded at the loading site of our factory using crane and forklift by our skilled workers,who will prevent the goods to be damaged.
Items | Questions | Answers |
1 | Are you manufacture factory or trading company? | We are manufacture factory. Welcomed to visit us at any time. The quality control flow and sales team will show you our professionalism. Also you will get best and most competitive price after visiting us. |
2 | Is your price competitive compared with other companies? | Our business objectives are to give the best price with same quality and best quality with the same price. We will do everything we can to reduce your cost and guarantee you get the best product that you paid for. |
3 | Can you send engineers or whole team to install my project? | We will give detailed installation drawings for free for each project before installation. We can send engineers to guide installation on site or a construction team to install directly. |
4 | Do you offer designing service for us? |
Yes, we could design full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) and etc. we can design proposal drawing, shop drawing, 3D Tekla model, construction/installation drawing to you. |
5 | What is the delivery time? |
Delivery time depends on order quantities. In general the delivery time to nearest seaport in China will be 40 days after receiving deposit. |
6. | How to pack and transport: | All the structure components, panels,bolts and sort of accessories will be well packed with standard package suitable ocean transportation and loaded into 40’HQ. |
