제품 상세 정보:
원래 장소: 중국
브랜드 이름: Ruly Steel
인증: SGS, BV, ISO
모델 번호: Ruly0307
결제 및 배송 조건:
최소 주문 수량: 300 평방 미터
가격: USD29-USD99 Per Square Meter
포장 세부 사항: 강철 구조 깔판과 40'로 적재해 HQ
배달 시간: 30 일
지불 조건: L/C (신용장), 전신환, 웨스턴 유니온
공급 능력: 달 당 20000 평방 미터

다층 강철 구조 건축 강철 창고 전 설계된 강철 구조물

설명
애플리케이션: 다중 층 철골 공사 타입: 조립식 강철 골조 구조 건물
익지않는 강철 물자: Q235B, Q355B, ASTM A36 서비스 수명: 50 년
벽과 지붕: 바위 모직 작동 범위: 디자인, 제작, 임명
란 & 광속: H 단면도 강철 표준: AISC, ASTM, BS, DIN, GB, JIS
하이 라이트:

다층 철골 구조

,

ASTM A36 철골 구조

,

다층 사전 설계된 철골 구조

Multi Storey Steel Frame Construction Steel Warehouse Pre Engineered Steel Structure



Multi Storey Steel Frame Construction Steel Warehouse Pre Engineered Steel Structure.It is a five-storey steel frame structure built as a parking building.Steel structural members are mainly composed of steel beams, steel columns, steel trusses and other members made of steel and steel plates.Due to the overall stiffness and seismic performance of the steel structure, the construction speed is fast, the weight is light, the bearing capacity is high, and the span is large, the reinforced concrete structure has been replaced by the super high-rise building.Welds, bolts, or rivets are commonly used to join the various parts or members of a steel structure.

Qingdao Ruly Steel Engineering Co.,Ltd is a professional steel structure fabrication and construction company for light and heavy steel structure project. Our service include design, fabrication for all the steel structure components and insullation panel, installation on site.

Specification of steel structure material:



Items Specification
Main Steel Frame Column Q235, Q355 Welded H Section Steel
Beam Q235, Q355 Welded H Section Steel
Secondary Frame Purlin Q235 C and Z purlin
Knee brace Q235 Angle Steel
Tie Rod Q235 Circular Steel Pipe
Brace Q235 Round Bar
Vertical and Horizontal Support Q235 Angle Steel, Round Bar or Steel Pipe
Maintenance system Roof Panel EPS Sandwich Panel / Glass Fiber Sandwich Panel /
Rock Wool Sandwich Panel / Pu Sandwich Panel /Steel Sheet
Wall Panel Sandwich Panel / Corrugated Steel Sheet
Accessories Window Aluminiumn Alloy Window / PVC Window / Sandwich Panel Window
Door Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door
Rainspout PVC
Live load on Roof In 120kg/Sqm (Color steel panel surrounded)
Wind Resistance Grade 12 Grades
Earthquake-resistance 8 Grades
Structure Usage Up to 50 years
Temperature Suitable temperature.-50°C~+50°C
Certification CE, SGS, ISO9001:2008, ISO14001:2004
Finishing Options Vast array of colors and textures available
Paint Options Alkyd paiting, two primary painting, two finish painting
(gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized.



Our steel structure fabrication factory:

The floor space of our steel structre fabrication factory is 35,000㎡, and the workshop area is 20000㎡. We own three light/heavy H steel production lines, BOX production lines, C/Z purlin production lines and various types of profiling steel sheet machines with advanced equipment such as plasma cutting machine.

다층 강철 구조 건축 강철 창고 전 설계된 강철 구조물 0



Our services:

We can design and fabricate customized steel structure components for light and heavy steel structure buildings in protal frame and dome frame, such as warehouse, workshop, storage, hangar, chicken shed, steel shed for market and ground parking, supermarket , high rise steel office buiding, factory , plant, exhibition hall, gym, dormitory building, oli&gas, power station, infrastructure buildings, etc.

다층 강철 구조 건축 강철 창고 전 설계된 강철 구조물 1



Q&A:

1- Are you factory or trading company?
We are factory.

2- What kinds of structural steel do you produce?
Steel columns, variable cross-section columns, cross columns, H beams, arc-shape H beams, two cross-section beams, variable cross-section beams, box beams, tie beams, sectioned beams, arc-shape beams, castellated beams, etc.

3- Where to use your structural steel?
Steel structure buildings, warehouse, workshop, factory, office building, shopping mall, hospital, apartment, etc.

4- What equipment do you have for manufacturing?
CNC cutting machine, H-Beam Auto Assembly Machine, Auto submerged arc welding machine, Flange Straightening Machine, Hydraulic Brake Type Plate, Shearing Machine, Numerical Control Cutting Machine, Three Torches Straightline Cutting Machine, Magnetic drill machine, Intelligent&Manual Welder, Air Compressor, Sandblasting Machine,etc.

5- What welding standard do you use during processing?
GB, JIS, ASTM.

6- What method do you use for packing?
Steel pallet on the bottom, wood among each layer and cable for fastening, or as per your requirements.

For any other question or further discusstion, please send us inquiry or email!
